Woven bag palletizing line

Product Description
Technical Parameters

PP Woven Bag Extrusion Pelletizing Machine Applications:

PP woven bag extrusion pelletizing machine is a double-stage plastic regenerative pelletizer, which is suitable for many kinds of plastic waste materials recycling and making pellets, such as PP woven bags, PP raffia bags, PP jumbo bag scrap material, and more. The PP woven bag can be pressed in the compressor and then be pelletized.

Applicable plastic materials: PP woven bag, PP raffia bag, PP jumbo bag, cement bag, sand woven bag, chemical bag, etc.
Material shapes: film, woven bag, fiber, rope scrap.
Material types: rolls, loose, bundled.
Material comes from offcut, industry defective materials, washed materials, and printed materials.

Note: Depending on different material properties, various downstream equipment is needed.

PP Woven Bag Extrusion Pelletizing Machine Description:

The double-stage PP woven bag extrusion pelletizing machine is especially good for raw materials that contain high moisture and high impurities. The first stage extruder adopts an exhaust-type barrel screw, which can effectively de-gas and eliminate moisture and contamination. The second extruder usually adopts a small L/D extruder, further plasticizing the material and filtering contamination to achieve stable extrusion.

PP Woven Bag Extrusion Pelletizing Machine Process Flow:

Conveying feeding → Metal detector → Woven bag agglomerator/compactor → 1# Degassing screw extruder → 1# Hydraulic filter exchanger → 2# Screw extruder → 2# Hydraulic filter exchanger → Mould head → Water ring cutting → Dewatering machine → Air dryer blowing system → Storage hopper → Finished product packing.

Detailed Description of Each Item:

Conveyor: Convey PP woven bags or flakes into the compactor.
PP Woven Bag Agglomerator/Compactor: Crushes and compresses woven bags, feeding compressed woven bags into the extruder to ensure high and stable production capacity.
1# Extruding System: Plasticizes material and exhausts gas.
1# High-Speed Net Exchanging System: Filters material impurities, making production more stable.
2# Extruding System: Further plasticizes material.
2# High-Speed Net Exchanging System and Die-head: Second filtering of material impurities to ensure stable production.
Water Ring Pelletizing Machine: Cuts pellets in water.
Water Tank: Cools pellets.
Dewater Machine: Dries pellets.
Vibration Sieve: Removes bad pellets and keeps good pellets.
Air Blower: Conveys good pellets into the silo.
Storage Silo: Keeps pellets.

PP Woven Bag Extrusion Pelletizing Machine Features:

Allows free assembling of the screw component based on raw material type.
Uses the suitable die head for pelletizing, such as water ring cutting, under-water cutting, and hot face cutting.
High efficient force feeder ensures stable high-capacity material feeding with low power consumption.
Main screw has vacuum exhaustion.
Water ring granulator machine, attached with a dryer.
Single screw extruder, with specially designed screw, barrel, and venting system, ensures the good quality of the final products.
Pelletizing style: standard cutting with extrusion mould. Even cutting ensures good shape.

Model	Screw Dia（mm）	L/D	Capacity (kg/h)
PNHS-85/85	85	25-36	120-180
PNHS-100/100	100	25-36	200-250
PNHS-130/130	130	25-33	400-500
PNHS-160/160	160	25-33	450-700
PNHS-180/180	180	25-33	500-1000
