Single shaft shredder

Product Description
Technical Parameters

Waste Plastic HDPE Bottle Flake Pelletizing Machine Description:

Plastic flake pelletizing machine for waste plastic recycling is used to make plastic flakes into pellets or granules.

Single shaft shredder Applications:

The single-axis water-cooled TPU rubber shredder is mainly used to shred TPU rubber waste into small pieces for easy recycling and reuse. Its water-cooling technology helps to reduce the temperature during the shredding process, maintain stable equipment operation, and extend its service life. This device is not only suitable for TPU rubber but also for processing other rubber waste, achieving effective resource recycling and reducing environmental pollution.

Single shaft shredder Description:

European-type single shaft shredders are designed for a wide array of applications and industries, such as indoor and general recycling, electronic waste, wood, organic waste, and more. The input material can be all kinds of plastic like lumps, pipes, films, woven bags. The size of the output material can be controlled by the screen size. Meantime, the shredded material can be better used or go into a granulator machine.

Single shaft shredder Components:

Pusher System: Reinforced baseplate can reduce the impact caused by material entering the cutting chamber. A dust collection device is equipped at the bottom of the pusher system to guarantee the long-term stable performance of internal components.
Heat treated rotor knives Special DC53 steel (hardened) four edges use before the replacement
V-cutting rotor design with staggered cutter positioning
Wear Resistant Tungsten surface coating for abrasive applications
Cooling systems water-cooled and air-cooled systems. In the Middle East and North Africa, where the temperature is particularly high, water cooling is required; in other less hot countries, such as Chile and Northern Europe, air cooling is sufficient
Screen Unit Wide range of screens with a variety of configurations and mesh sizes are replaceable based on customers’ production requirements. The paper shredder will automatically stop while opening the screen unit to ensure operator safety. The screen is produced and mounted in sections, allow for easy maintenance.
PLC control Making it easier for fault diagnosis and maintenance
Hydraulic Station The pressure and rate of flow can be adjusted according to different materials.

Single shaft shredder Features:

Precisely processed combined frame made of extra-thick plates; Lange-angle, hexagon prism of power slewing axis; Big hopper with big caliber for feeding big material;
PLC control system with automatic overload protection and auto-reverse switch;
Unique hydraulic pushing system accelerates the shredding speed, for light material particularly;
Each dynamic blades has four cutting edges which enable reutilization after being abraded, by rotating 90 degrees;
Each fixed blade has two cutting edges which enable reutilization after being abraded, by rotating 180 degrees;
Quiet operation at low speed;
Screen perforation is adjustable according to customers’ requirements;
Sponge Shredders can be adjusted according to customer-specific requirements for throughput volume, material to be processed, etc.

Model	PNDS-600A	PNDS-800A	PNDS-1000A	PNDS-1200A	PNDS-1500A
Model	PNDS-600A	PNDS-800A	PNDS-1000A	PNDS-1200A	PNDS-1500A
Dimension LWH(mm)	2455×1478×1700	2825×1747×1875	2825×2004×1875	2825×2564×1875	2825×2964×1935
Cutting Chamber C/D(mm)	1200×600	1410×800	1410×1000	1410×1200	1410×1500
Main Power(kw)	15-22	30-45	37-55	55-90	75-132
Hydraulic Power(kw)	2,2	3	4	5.5	5.5
Shredding Diameter(mm)	320	400	400	400	480
Shredding Rotor Length(mm)	600	800	1000	1200	1500
Rotating&Fixing Blades QTY(psc)	32+2×2	38+2×2	58+2×2	95+2×3	110+2×3
End Plastic Scraps Size(mm)	30-50	30-50	30-50	30-50	30-50
